CumulativeDelta

#property copyright “Sciurus 2015”

#property indicator_separate_window
#property indicator_buffers 17

#import “user32.dll”
int GetDC(int hwnd);
int ReleaseDC(int hwnd,int hdc);
#import “gdi32.dll”
color GetPixel(int hdc,int x,int y);
#import

extern bool showCumulative = true;
extern bool recordTicks = true;
extern bool printHistory = true;
extern color dnColor = Crimson;
extern color upColor = Green;
extern bool showCorr = false;
extern int corrPeriod = 20;

double closed[],opened[],highed[],lowed[];

static double Up_Body_Green[];
static double Dn_Body_Red[];
static double EqBodyBuffer[];
static double Bg_Body_Black[];
static double Up_Wick_Green[];
static double Dn_Wick_Red[];
static double EqShadowBuffer[];
static double Bg_Wick_Black[];
static double Dn_Body_Green[];
static double Up_Body_Red[];
static double Dn_Wick_Green[];
static double Up_Wick_Red[];
static double correlation[];

double Curr_Bid;
double Prev_Bid;
double Curr_Ask;
double Prev_Ask;
double Curr_Vol;
double Prev_Vol;
datetime timestamp;
color bkg_color;
int handle=0;
bool firstTick=true;

int init() {

IndicatorBuffers(17);
SetIndexBuffer(0,closed); SetIndexEmptyValue(0,0); SetIndexStyle(0,DRAW_NONE);
SetIndexBuffer(1,opened); SetIndexEmptyValue(1,0); SetIndexStyle(1,DRAW_NONE);
SetIndexBuffer(2,highed); SetIndexEmptyValue(2,0); SetIndexStyle(2,DRAW_NONE);
SetIndexBuffer(3,lowed); SetIndexEmptyValue(3,0); SetIndexStyle(3,DRAW_NONE);
SetIndexBuffer(4,Up_Body_Green); SetIndexEmptyValue(4,0); SetIndexStyle(4,DRAW_HISTOGRAM,STYLE_SOLID,3,upColor);
SetIndexBuffer(5,Dn_Body_Red); SetIndexEmptyValue(5,0); SetIndexStyle(5,DRAW_HISTOGRAM,STYLE_SOLID,3,dnColor);
SetIndexBuffer(6,EqBodyBuffer); SetIndexEmptyValue(6,0); SetIndexStyle(6,DRAW_HISTOGRAM,STYLE_SOLID,3,White);
SetIndexBuffer(7,Bg_Body_Black); SetIndexEmptyValue(7,0); SetIndexStyle(7,DRAW_HISTOGRAM,STYLE_SOLID,3,bkg_color);
SetIndexBuffer(8,Up_Wick_Green); SetIndexEmptyValue(8,0); SetIndexStyle(8,DRAW_HISTOGRAM,STYLE_SOLID,1,upColor);
SetIndexBuffer(9,Dn_Wick_Red); SetIndexEmptyValue(9,0); SetIndexStyle(9,DRAW_HISTOGRAM,STYLE_SOLID,1,dnColor);
SetIndexBuffer(10,EqShadowBuffer); SetIndexEmptyValue(10,0); SetIndexStyle(10,DRAW_HISTOGRAM,STYLE_SOLID,1,White);
SetIndexBuffer(11,Bg_Wick_Black); SetIndexEmptyValue(11,0); SetIndexStyle(11,DRAW_HISTOGRAM,STYLE_SOLID,1,bkg_color);
SetIndexBuffer(12,Dn_Body_Green); SetIndexEmptyValue(12,0); SetIndexStyle(12,DRAW_HISTOGRAM,STYLE_SOLID,3,upColor);
SetIndexBuffer(13,Up_Body_Red); SetIndexEmptyValue(13,0); SetIndexStyle(13,DRAW_HISTOGRAM,STYLE_SOLID,3,dnColor);
SetIndexBuffer(14,Dn_Wick_Green); SetIndexEmptyValue(14,0); SetIndexStyle(14,DRAW_HISTOGRAM,STYLE_SOLID,1,upColor);
SetIndexBuffer(15,Up_Wick_Red); SetIndexEmptyValue(15,0); SetIndexStyle(15,DRAW_HISTOGRAM,STYLE_SOLID,1,dnColor);
SetIndexBuffer(16,correlation); SetIndexEmptyValue(16,0); SetIndexStyle(16,DRAW_LINE, STYLE_SOLID, 2, Yellow);

int load = iBars(Symbol(),0); // force load bars in history

closed[1]=0;
opened[1]=0;
highed[1]=0;
lowed[1]=0;
closed[0]=0;
opened[0]=0;
highed[0]=0;
lowed[0]=0;

return (0);
}

/////////////////////////////////////////////////////////////////////////////
// DEINITIALIZATION FUNCTION //
/////////////////////////////////////////////////////////////////////////////

int deinit() {

if (handle==1){
FileClose(handle);
}
return (0);
}

/////////////////////////////////////////////////////////////////////////////
// START FUNCTION: PERFORM ON EVERY TICK //
/////////////////////////////////////////////////////////////////////////////

int start(){

//Handle the background color. This function will set the background color to the pixel at location 1,2
int hwnd=WindowHandle(Symbol(),Period());
int hdc=GetDC(hwnd);
bkg_color=GetPixel(hdc,1,2);
ReleaseDC(hwnd,hdc);
if (bkg_color!=4294967295)//4294967295 is the code for NONE, and hence I don’t want to be showing that color if the edge of the window is off screen or if there is another window on top of mt4
{
SetIndexStyle(7,DRAW_HISTOGRAM,STYLE_SOLID,3,bkg_color);
SetIndexStyle(11,DRAW_HISTOGRAM,STYLE_SOLID,3,bkg_color);
}

Prev_Bid = Curr_Bid;
Curr_Bid = Bid;
Prev_Ask = Curr_Ask;
Curr_Ask = Ask;
Prev_Vol = Curr_Vol;
Curr_Vol = iVolume(NULL,0,0);

if (Time[0]!=timestamp && firstTick==false && showCumulative==true)
{
closed[0]=closed[1];
opened[0]=closed[1];
highed[0]=closed[1];
lowed[0]=closed[1];
Prev_Vol=iVolume(NULL,0,0);
timestamp=Time[0];
}

if (Time[0]!=timestamp && firstTick==false && showCumulative==false)
{
closed[0]=0;
opened[0]=0;
highed[0]=0;
lowed[0]=0;
Prev_Vol=iVolume(NULL,0,0);
timestamp=Time[0];
}

if (firstTick==true) initialize(); //function that will open appropriate files, read from them, and set basic global tick values to initial values

// write Bid/Ask tick data to file
if (recordTicks==true && (Curr_Vol-Prev_Vol > 0 && (Prev_Ask!=Curr_Ask || Prev_Bid!=Curr_Bid)))
{
FileSeek(handle, 0, SEEK_END);
FileWrite(handle,TimeToStr( TimeCurrent(), TIME_DATE | TIME_SECONDS ),Bid, Ask, Curr_Vol-Prev_Vol);
}

updateTickValues(); // Function to update values based upon incoming tick and volume values

printBar(0); // function to print our a bar using the histogram function for the current global tick values

if (showCorr==true) calcCorr(); // function to calculate Pearson’s correlation coefficient

return (0);
}

/////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
// Function that will open appropriate files, read from them, and set basic global tick values to initial values //
/////////////////////////////////////////////////////////////////////////////////////////////////////////////////////

void initialize(){

if (printHistory==true){
handle=FileOpen(“Ticks_”+Symbol()+”.csv”, FILE_CSV|FILE_READ|FILE_WRITE,’,’);
if (handle<0){
Print(“Could Not Create/Open File “+GetLastError());
FileClose(handle);
}
if (handle==1){
Print(“File Opened Successfully”);
FileSeek(handle,0,SEEK_SET);
if (!FileIsEnding(handle)) readData(); //Function to Read data line by line from file starting from the earliest record
}
}

if (recordTicks==true && handle==0){
handle=FileOpen(“Ticks_”+Symbol()+”.csv”, FILE_CSV|FILE_READ|FILE_WRITE,’,’);
if (handle<0){
Print(“Could Not Create/Open File “+GetLastError());
FileClose(handle);
}
if (handle==1) Print(“File Opened Successfully”);
FileSeek(handle, 0, SEEK_END);
}

if (recordTicks==true && handle==1){
FileSeek(handle, 0, SEEK_END);
}

Prev_Vol=iVolume(NULL,0,0);
Curr_Vol=iVolume(NULL,0,0);
firstTick=false;
}

//////////////////////////////////////////////////////////////////////////////////////
// Function to Read data line by line from file starting from the earliest record //
//////////////////////////////////////////////////////////////////////////////////////
void readData(){
datetime time1 = StrToTime(FileReadString(handle));
double bid1 = StrToDouble(FileReadString(handle));
double ask1 = StrToDouble(FileReadString(handle));
double volume1 = StrToDouble(FileReadString(handle));

int i=0;
while (time1<=Time[i]){
i++;
}

opened[i]=0;
closed[i]=0;
highed[i]=0;
lowed[i]=0;

datetime time2=time1;

for (i; i>-1; i–){
if (i>0){
while ((time2<Time[i-1]) && !FileIsEnding(handle)){
time2 = StrToTime(FileReadString(handle));
double bid2 = StrToDouble(FileReadString(handle));
double ask2 = StrToDouble(FileReadString(handle));
double volume2 = StrToDouble(FileReadString(handle));
if (ask2>ask1){
closed[i]=closed[i]+volume2;
}
if (bid2<bid1){
closed[i]=closed[i]-volume2;
}
if (closed[i]>highed[i]){
highed[i]=closed[i];
}
if (closed[i]<lowed[i]){
lowed[i]=closed[i];
}

if (showCumulative==false){
closed[i]=closed[i]-opened[i];
highed[i]=highed[i]-opened[i];
lowed[i]=lowed[i]-opened[i];
opened[i]=0;
}

printBar(i);
time1=time2;
bid1=bid2;
ask1=ask2;
volume1=volume2;
}
}

if (i==0){
while (!FileIsEnding(handle)){
time2 = StrToTime(FileReadString(handle));
bid2 = StrToDouble(FileReadString(handle));
ask2 = StrToDouble(FileReadString(handle));
volume2 = StrToDouble(FileReadString(handle));
if (ask2>ask1){
closed[i]=closed[i]+volume2;
}
if (bid2<bid1){
closed[i]=closed[i]-volume2;
}
if (closed[i]>highed[i]){
highed[i]=closed[i];
}
if (closed[i]<lowed[i]){
lowed[i]=closed[i];
}
printBar(i);
time1=time2;
bid1=bid2;
ask1=ask2;
volume1=volume2;
}
}
opened[i-1]=closed[i];
highed[i-1]=closed[i];
lowed[i-1]=closed[i];
closed[i-1]=closed[i];
}

}

/////////////////////////////////////////////
// Create a OHLC bar from the tick data //
/////////////////////////////////////////////

void printBar(int pos){

if (closed[pos]>0 && opened[pos]>=0 && lowed [pos]>=0 && highed[pos]>0){

if (closed[pos]>opened[pos]){
Up_Body_Green[pos] = closed[pos];
Bg_Body_Black[pos] = opened[pos];
Up_Wick_Green[pos] = highed[pos];
Bg_Wick_Black[pos] = lowed[pos];

Up_Wick_Red[pos]=0;
Up_Body_Red[pos]=0;
Dn_Wick_Red[pos]=0;
Dn_Body_Red[pos]=0;

}
if (closed[pos]<opened[pos]){
Dn_Body_Red[pos] = opened[pos];
Bg_Body_Black[pos] = closed[pos];
Dn_Wick_Red[pos] = highed[pos];
Bg_Wick_Black[pos] = lowed[pos];

Up_Wick_Green[pos]=0;
Up_Body_Green[pos]=0;
Dn_Wick_Green[pos]=0;
Dn_Body_Green[pos]=0;

}

}
if (closed[pos]>=0 && opened[pos]>=0 && lowed [pos]<0 && highed[pos]>0){

if (closed[pos]>opened[pos]){
Up_Body_Green[pos] = closed[pos];
Bg_Body_Black[pos] = opened[pos];
Up_Wick_Green[pos] = highed[pos];
Dn_Wick_Green[pos] = lowed[pos];

Up_Wick_Red[pos]=0;
Up_Body_Red[pos]=0;
Dn_Wick_Red[pos]=0;
Dn_Body_Red[pos]=0;

}
if (closed[pos]<opened[pos]){
Up_Body_Red[pos] = opened[pos];
Bg_Body_Black[pos] = closed[pos];
Up_Wick_Red[pos] = highed[pos];
Dn_Wick_Red[pos] = lowed[pos];

Up_Wick_Green[pos]=0;
Up_Body_Green[pos]=0;
Dn_Wick_Green[pos]=0;
Dn_Body_Green[pos]=0;

}
}
if (closed[pos]>0 && opened[pos]<0){

if (closed[pos]>opened[pos]){
Up_Body_Green[pos] = closed[pos];
Up_Wick_Green[pos] = highed[pos];
Dn_Body_Green[pos] = opened[pos];
Dn_Wick_Green[pos]= lowed[pos];

Up_Wick_Red[pos]=0;
Up_Body_Red[pos]=0;
Dn_Wick_Red[pos]=0;
Dn_Body_Red[pos]=0;
Bg_Body_Black[pos]=0;
Bg_Wick_Black[pos]=0;

}
}

if (closed[pos]<0 && opened[pos]<=0 && lowed [pos]<0 && highed[pos]<=0){
if (closed[pos]>opened[pos]){
Up_Body_Green[pos] = opened[pos];
Bg_Body_Black[pos] = closed[pos];
Up_Wick_Green[pos] = lowed[pos];
Bg_Wick_Black[pos] = highed[pos];

Up_Wick_Red[pos]=0;
Up_Body_Red[pos]=0;
Dn_Wick_Red[pos]=0;
Dn_Body_Red[pos]=0;
}
if (closed[pos]<opened[pos]){
Dn_Body_Red[pos] = closed[pos];
Bg_Body_Black[pos] = opened[pos];
Dn_Wick_Red[pos] = lowed[pos];
Bg_Wick_Black[pos] = highed[pos];

Up_Wick_Green[pos]=0;
Up_Body_Green[pos]=0;
Dn_Wick_Green[pos]=0;
Dn_Body_Green[pos]=0;
}
}

if (closed[pos]<=0 && opened[pos]<=0 && lowed[pos]<0 && highed[pos]>0){

if (closed[pos]>opened[pos]){
Up_Body_Green[pos] = opened[pos];
Bg_Body_Black[pos] = closed[pos];
Up_Wick_Green[pos] = highed[pos];
Dn_Wick_Green[pos] = lowed[pos];

Up_Wick_Red[pos]=0;
Up_Body_Red[pos]=0;
Dn_Wick_Red[pos]=0;
Dn_Body_Red[pos]=0;
}
if (closed[pos]<opened[pos]){
Dn_Body_Red[pos] = closed[pos];
Bg_Body_Black[pos] = opened[pos];
Up_Wick_Red[pos] = highed[pos];
Dn_Wick_Red[pos] = lowed[pos];

Up_Wick_Green[pos]=0;
Up_Body_Green[pos]=0;
Dn_Wick_Green[pos]=0;
Dn_Body_Green[pos]=0;

}
}

if (closed[pos]<0 && opened[pos]>0){

Dn_Body_Red[pos] = closed[pos];
Up_Wick_Red[pos] = highed[pos];
Up_Body_Red[pos] = opened[pos];
Dn_Wick_Red[pos] = lowed[pos];

Up_Wick_Green[pos]=0;
Up_Body_Green[pos]=0;
Dn_Wick_Green[pos]=0;
Dn_Body_Green[pos]=0;
Bg_Body_Black[pos]=0;
Bg_Wick_Black[pos]=0;

}
}

////////////////////////////////////////////////////////////////////////
// Function to Update Variables for Bar Creation (done every tick) //
////////////////////////////////////////////////////////////////////////

void updateTickValues(){

if (Curr_Ask > Prev_Ask){
closed[0]=closed[0]+(Curr_Vol-Prev_Vol);
if(closed[0]>highed[0]){
highed[0]=closed[0];
}
if(closed[0]<lowed[0]){
lowed[0]=closed[0];
}

}
if (Curr_Bid < Prev_Bid){
closed[0]=closed[0]-(Curr_Vol-Prev_Vol);
if(closed[0]>highed[0]){
highed[0]=closed[0];
}
if(closed[0]<lowed[0]){
lowed[0]=closed[0];
}
}
}

////////////////////////////////////////////////////////////////////////
// Function to Calculate Pearson’s Corellation Coefficient //
////////////////////////////////////////////////////////////////////////

void calcCorr(){

for (int i=Bars-1-corrPeriod; i>=0; i–){
double A=0;
double B=0;
double C=0;
double sumY, meanY;

for (int p = i+corrPeriod; p>=i; p–)
{
sumY = sumY+ (Close[p]-Open[p]);
} meanY=sumY/corrPeriod;
double sumX, meanX;

for (int r = i+corrPeriod; r>=i; r–)
{
sumX = sumX+ (closed[r]-opened[r]);
} meanX=sumX/corrPeriod;

for (int q = i+corrPeriod; q>=i; q–){
A=A + (closed[q]-opened[q]-meanX)*(Close[q]-Open[q]-meanY);
B=B + MathPow((closed[q]-opened[q]-meanX),2);
C=C + MathPow(Close[q]-Open[q]- meanY,2);
}
if (A!=0 && B!=0 && C!=0){
correlation [i] = 100*A/(MathSqrt(B)*MathSqrt(C));
}

}

}
