FXTT_Fx_Scanner

//+——————————————————————+
//| FXTT_StrategyChecklist.mq4 |
//| Copyright 2016, Carlos Oliveira |
//| https://www.forextradingtools.eu |
//+——————————————————————+
#property copyright “Copyright 2016, Carlos Oliveira”
#property link “https://www.forextradingtools.eu/products/indicators/forex-scanner-free-indicator/?utm_campaign=properties.indicator&utm_medium=special&utm_source=mt4terminal”
#property version “2.00”
#property strict
#property indicator_chart_window

string INDI_NAME=”MPSCN-“;

input int TimerInterval=60; //Update interval (secs)
input int FontSize=10; //Font Size
input string FontName=”Calibri”; //Font Name
input int ColumnHeight=50; //Max symbols per column

input string Group0; //—————————————————
input bool ShowPrice=true; //Show Price
input string Group01; //—————————————————
input bool ShowSpread=true; //Show Spread

input string Group1; //—————————————————
input bool ShowATR=true; //Show ATR
input ENUM_TIMEFRAMES AtrTimeframe=PERIOD_H1; //ATR Timeframe
input int AtrPeriod=20; //ATR Period

input string Group2; //—————————————————
input bool ShowVolume=true; //Show Volume
input ENUM_TIMEFRAMES VolumeTimeframe=PERIOD_H1; //Volume Timeframe
input int VolumePeriod=60; //Volume Period

input string Group3; //—————————————————
input bool ShowRsi=true; //Show RSI
input ENUM_TIMEFRAMES RsiTimeframe=PERIOD_H1; //RSI Timeframe
input int RsiPeriod=14; //RSI Period
input int RsiUpperLevel = 75; //RSI Upper Level
input int RsiLowerLevel = 25; //RSI Lower Level

input string Group4; //—————————————————
input bool ShowStoch=true; //Show Stochastic
input ENUM_TIMEFRAMES StochTimeframe=PERIOD_H1; //Stoch Timeframe
input int StochK = 5; //%K period
input int StochD = 3; //%D period
input int StochSlow = 3;//Slowing
input ENUM_MA_METHOD StochMethod=MODE_SMA; //MA Method
input ENUM_STO_PRICE StochPrice=STO_LOWHIGH; //Price Field
input int StochUpperLevel = 80; //Stoch Upper Level
input int StochLowerLevel = 20; //Stoch Lower Level

input string Group5; //—————————————————
input bool ShowAdx=true; //Show ADX
input ENUM_TIMEFRAMES AdxTimeframe=PERIOD_H1; //ADX Timeframe
input int AdxPeriod=20; //ADX Period
input ENUM_APPLIED_PRICE AdxAppliedPrice=PRICE_CLOSE; //ADX Applied Price

input string Group6; //—————————————————
input bool ShowPivots=true; //Show Pivots

input string Group7; //—————————————————
input bool ShowMA=true; //Show MA
input ENUM_TIMEFRAMES MATimeframe=PERIOD_H1; //MA Timeframe
input int MAPeriod=60; //MA Period
input ENUM_MA_METHOD MAMethod=MODE_SMA; //MA Method
input ENUM_APPLIED_PRICE MAAppliedPrice=PRICE_CLOSE; //MA Applied

int GUIXOffset = 20;
int GUIYOffset = 45;

int GUIHeaderXOffset = 20;
int GUIHeaderYOffset = 0;

int GUIColOffset=100;

int ListXOffset = 10;
int ListYOffset = 15;

int ListXMultiplier = 10;
int ListYMultiplier = 15;

datetime TimeMissing;
//+——————————————————————+
//| Custom indicator initialization function |
//+——————————————————————+
int OnInit()
{
//— indicator buffers mapping
ChartColorSet(CHART_COLOR_BACKGROUND,clrBlack);
ChartColorSet(CHART_COLOR_FOREGROUND,clrWhite);
ChartColorSet(CHART_COLOR_GRID,clrNONE);
ChartColorSet(CHART_COLOR_VOLUME,clrNONE);
ChartColorSet(CHART_COLOR_CHART_UP,clrNONE);
ChartColorSet(CHART_COLOR_CHART_DOWN,clrNONE);
ChartColorSet(CHART_COLOR_CHART_LINE,clrNONE);
ChartColorSet(CHART_COLOR_CANDLE_BULL,clrNONE);
ChartColorSet(CHART_COLOR_CANDLE_BEAR,clrNONE);
ChartColorSet(CHART_COLOR_BID,clrNONE);
ChartColorSet(CHART_COLOR_ASK,clrNONE);
ChartColorSet(CHART_COLOR_LAST,clrNONE);
ChartColorSet(CHART_COLOR_STOP_LEVEL,clrNONE);
ChartModeSet(CHART_LINE);
//—
EventSetTimer(1);

DrawHeader();
DrawScanner();

return(INIT_SUCCEEDED);
}
//+——————————————————————————————-+
int deinit()
{
ObjectsDeleteAll(ChartID(),INDI_NAME);
return(0);
}
//+——————————————————————+
//| Custom indicator iteration function |
//+——————————————————————+
int OnCalculate(const int rates_total,
const int prev_calculated,
const datetime &time[],
const double &open[],
const double &high[],
const double &low[],
const double &close[],
const long &tick_volume[],
const long &volume[],
const int &spread[])
{
DrawMissingTime();
//— return value of prev_calculated for next call
return(rates_total);
}
//+——————————————————————+
//| Timer function |
//+——————————————————————+
void OnTimer()
{
DrawMissingTime();
if(TimeSeconds(TimeCurrent())%TimerInterval==0)
{
DrawScanner();
}
}
//+——————————————————————+
//| |
//+——————————————————————+
long getAvgVolume(string symbol,int period)
{
long volume_total=0;
for(int i=0; i<period; i++)
{
volume_total+=iVolume(symbol,VolumeTimeframe,i);
}
return volume_total / period;
}
//+——————————————————————+
//| |
//+——————————————————————+
double getRange(string symbol,int period)
{
int DataPeriod=PERIOD_D1;
int DataBar=iBarShift(symbol,DataPeriod,Time[0]);
double range = iHigh(symbol, period, DataBar) – iLow(symbol, period, DataBar);
double point = MarketInfo(symbol, MODE_POINT);
if(point > 0) return (NormalizeDouble(range / point, 0));
return 1;
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawMissingTime(int deltaY=0)
{
int x=GUIXOffset+ListXOffset,y=20;

DrawLabel(“CurTimeLbl”,x,y,”Server Time:”+TimeToStr(TimeCurrent(),TIME_MINUTES),FontSize,FontName,clrWhite);
DrawLabel(“LocalTimeLbl”,x+=150,y,”Local Time:”+TimeToStr(TimeLocal(),TIME_MINUTES),FontSize,FontName,clrWhite);
DrawLabel(“TimeLeftLbl”,x+=150,y,”Time until Candle close:”,FontSize,FontName,clrWhite);
DrawTimeMissingColum(PERIOD_M1,x+=150,y);
DrawTimeMissingColum(PERIOD_M5,x+=GUIColOffset,y);
DrawTimeMissingColum(PERIOD_M15,x+=GUIColOffset,y,30);
DrawTimeMissingColum(PERIOD_H1,x+=GUIColOffset, y);
DrawTimeMissingColum(PERIOD_H4,x+=GUIColOffset, y);
DrawTimeMissingColum(PERIOD_D1,x+=GUIColOffset, y);
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawTimeMissingColum(int period,int x,int y,int dxOffset=25)
{
int dx=x;
color timeColor;
string periodStr= GetPeriodStr(period);
string timeLeft = GetTimeToClose(period, timeColor);

DrawLabel(“TimeLeftLbl_”+periodStr,dx,y,periodStr+”:”,FontSize,FontName,clrWhite);
DrawLabel(“TimeLeftVal_”+periodStr,dx+=dxOffset,y,timeLeft,FontSize,FontName,timeColor);

}
//+——————————————————————+
//| |
//+——————————————————————+
string GetTimeToClose(int period,color &timeColor)
{
int periodMinutes = periodToMinutes(period);
int shift = periodMinutes*60;
int currentTime = (int)TimeCurrent();
int localTime = (int)TimeLocal();
int barTime = (int)iTime(period);
int diff = (int)MathMax(round((currentTime-localTime)/3600.0)*3600,-24*3600);

string time=getTime(barTime+periodMinutes*60-localTime-diff,timeColor);
time=(TerminalInfoInteger(TERMINAL_CONNECTED)) ? time : time+” x”;

return time;
}
//+——————————————————————+

void DrawLabel(string name,int x,int y,string label,int size=9,string font=”Arial”,color clr=DimGray,string tooltip=””)
{
name=INDI_NAME+”:”+name;
ObjectDelete(name);
ObjectCreate(name,OBJ_LABEL,0,0,0);
ObjectSetText(name,label,size,font,clr);
ObjectSet(name,OBJPROP_CORNER,0);
ObjectSet(name,OBJPROP_XDISTANCE,x);
ObjectSet(name,OBJPROP_YDISTANCE,y);
ObjectSetString(0,name,OBJPROP_TOOLTIP,tooltip);
//— justify text
//ObjectSet(name, OBJPROP_ANCHOR, 0);
//ObjectSetString(0, name, OBJPROP_TOOLTIP, tooltip);
//ObjectSet(name, OBJPROP_SELECTABLE, 0);
//—
}
//+——————————————————————+
//| The function sets chart background color. |
//+——————————————————————+
bool ChartColorSet(int prop_id,const color clr,const long chart_ID=0)
{
//— reset the error value
ResetLastError();
//— set the chart background color
if(!ChartSetInteger(chart_ID,prop_id,clr))
{
//— display the error message in Experts journal
Print(__FUNCTION__+”, Error Code = “,GetLastError());
return(false);
}
//— successful execution
return(true);
}
//+——————————————————————+
//| Set chart display type (candlesticks, bars or |
//| line). |
//+——————————————————————+
bool ChartModeSet(const long value,const long chart_ID=0)
{
//— reset the error value
ResetLastError();
//— set property value
if(!ChartSetInteger(chart_ID,CHART_MODE,value))
{
//— display the error message in Experts journal
Print(__FUNCTION__+”, Error Code = “,GetLastError());
return(false);
}
//— successful execution
return(true);
}
//+——————————————————————+

//+——————————————————————+
void DrawScanner()
{
Print(“=============>DrawScanner”);
for(int x=0; x<SymbolsTotal(true); x++)
{
DrawSymbol(SymbolName(x,true),x);
}
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawSymbol(string symbolName,int symbolIdx)
{
int yMult = (int)fmod(symbolIdx, ColumnHeight);
int xMult = (symbolIdx/ColumnHeight);
int x= (GUIXOffset+GUIHeaderXOffset) + (NumVisibleColumns()*GUIColOffset)*xMult;
int y= GUIYOffset+ListYOffset + ListYMultiplier * yMult;
int colOffset=GUIColOffset;

DrawSymbolColumn(symbolName,x,y,symbolName,FontSize,FontName);

if(ShowPrice)
DrawPriceColumn(symbolName,x+=colOffset,y,symbolName,FontSize,FontName);
if(ShowSpread)
DrawSpreadColumn(symbolName,x+=colOffset,y,symbolName,FontSize,FontName);
if(ShowATR)
DrawRangeColumn(symbolName,x+=colOffset,y,symbolName,FontSize,FontName);
if(ShowVolume)
DrawVolumeColumn(symbolName,x+=colOffset,y,symbolName,FontSize,FontName);
if(ShowRsi)
DrawRsiColumn(symbolName,x+=colOffset,y,symbolName,FontSize,FontName);
if(ShowStoch)
DrawStochColumn(symbolName,x+=colOffset,y,symbolName,FontSize,FontName);
if(ShowAdx)
DrawAdxColumn(symbolName,x+=colOffset,y,symbolName,FontSize,FontName);
if(ShowPivots)
DrawPivotsColumn(symbolName,x+=colOffset,y,symbolName,FontSize,FontName);
if(ShowMA)
DrawMAColumn(symbolName,x+=colOffset,y,symbolName,FontSize,FontName);
}
//+——————————————————————+
//| |
//+——————————————————————+

double getPoint(string symbol)
{
return MarketInfo(symbol,MODE_POINT);
}
//+——————————————————————+
//| |
//+——————————————————————+
double getModifier(string symbol)
{
int digits=(int)MarketInfo(symbol,MODE_DIGITS);
double modifier=1;
if(digits==3 || digits==5)
modifier=10.0;
return modifier;
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawRsiColumn(string symbolName,int x,int y,string text,int fontSize=8,string fontName=”Calibri”)
{
double rsi=NormalizeDouble(iRSI(symbolName,RsiTimeframe,RsiPeriod,PRICE_CLOSE,0),0);
string tooltip=symbolName+”\n.: “+GetPeriodStr(RsiTimeframe)+” RSI (“+IntegerToString(RsiPeriod)+”):.\nCurrent (“+DoubleToStr(rsi,1)+”)”;
DrawLabel(“rsi_”+symbolName,x,y,DoubleToStr(rsi,1),fontSize,fontName,GetRsiColor(rsi),tooltip);
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawStochColumn(string symbolName,int x,int y,string text,int fontSize=8,string fontName=”Calibri”)
{
double stoch=iStochastic(symbolName,StochTimeframe,StochK,StochD,StochSlow,StochMethod,StochPrice,MODE_MAIN,0);
string tooltip=symbolName+”\n.: “+GetPeriodStr(StochTimeframe)+” Stoch :.\nCurrent (“+DoubleToStr(stoch,1)+”)”;
DrawLabel(“stoch_”+symbolName,x,y,DoubleToStr(stoch,1),fontSize,fontName,GetStochColor(stoch),tooltip);
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawAdxColumn(string symbolName,int x,int y,string text,int fontSize=8,string fontName=”Calibri”)
{
double adx=iADX(symbolName,AdxTimeframe,AdxPeriod,AdxAppliedPrice,MODE_MAIN,0);
string tooltip=symbolName+”\n.: “+GetPeriodStr(AdxTimeframe)+” ADX (“+IntegerToString(AdxPeriod)+”):.\nCurrent (“+DoubleToStr(adx,1)+”)”;
DrawLabel(“adx_”+symbolName,x,y,GetAdxStr(adx),fontSize,fontName,GetAdxColor(adx),tooltip);
}
//+——————————————————————+
//| |
//+——————————————————————+
string GetAdxStr(double adx)
{
if(adx<=25)
return “No Trend”;
if(adx<=50)
return “Weak Trend”;
if(adx<=75)
return “Strong Trend”;
return “Very Strong Trend”;
}
//+——————————————————————+
//| |
//+——————————————————————+
color GetAdxColor(double adx)
{
if(adx<=25)
return clrWhite;
if(adx<=50)
return clrGreen;
if(adx<=75)
return clrYellow;
return clrRed;
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawPriceColumn(string symbolName,int x,int y,string text,int fontSize=8,string fontName=”Calibri”)
{
int digits=(int)MarketInfo(symbolName,MODE_DIGITS);
double vAsk=NormalizeDouble(MarketInfo(symbolName,MODE_ASK),digits);
double vBid=NormalizeDouble(MarketInfo(symbolName,MODE_BID),digits);
double vSpread=NormalizeDouble(MarketInfo(symbolName,MODE_SPREAD),digits);
string tooltip=symbolName+”\n.: Price :.\nAsk: “+(string)vAsk+”\nBid: “+(string)vBid+”\nSpread: “+(string)vSpread;
DrawLabel(“price_”+symbolName,x,y,(string)vBid+”:”+ IntegerToString(x),fontSize,fontName,clrWhite,tooltip);
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawSpreadColumn(string symbolName,int x,int y,string text,int fontSize=8,string fontName=”Calibri”)
{
int digits=(int)MarketInfo(symbolName,MODE_DIGITS);
double vAsk=NormalizeDouble(MarketInfo(symbolName,MODE_ASK),digits);
double vBid=NormalizeDouble(MarketInfo(symbolName,MODE_ASK),digits);
double vSpread=NormalizeDouble(MarketInfo(symbolName,MODE_SPREAD),digits);
string tooltip=symbolName+”\n.: SPREAD :.\nAsk: “+(string)vAsk+”\nBid: “+(string)vBid+”\nSpread: “+(string)vSpread;
DrawLabel(“spread_”+symbolName,x,y,(string)vSpread,fontSize,fontName,clrWhite,tooltip);
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawPivotsColumn(string symbolName,int x,int y,string text,int fontSize=8,string fontName=”Calibri”)
{
double pivots[7];
int digits=(int)MarketInfo(symbolName,MODE_DIGITS);
double vAsk=MarketInfo(symbolName,MODE_BID);
double pivot=NormalizeDouble((GetPivotValue(symbolName,PERIOD_D1)),digits);

pivots[0]=pivot;

pivots[1]=NormalizeDouble((GetPivotResistance(symbolName,PERIOD_D1,pivot,1)),digits);
pivots[2]=NormalizeDouble((GetPivotResistance(symbolName,PERIOD_D1,pivot,2)),digits);
pivots[3]=NormalizeDouble((GetPivotResistance(symbolName,PERIOD_D1,pivot,3)),digits);

pivots[4]=NormalizeDouble((GetPivotSupport(symbolName,PERIOD_D1,pivot,1)),digits);
pivots[5]=NormalizeDouble((GetPivotSupport(symbolName,PERIOD_D1,pivot,2)),digits);
pivots[6]=NormalizeDouble((GetPivotSupport(symbolName,PERIOD_D1,pivot,3)),digits);

int closestIdx=GetClosestPivot(vAsk,pivots);
double pips=vAsk-pivots[closestIdx];

string tooltip=symbolName+”\n.: Daily Pivots :.\nPP: “+DoubleToStr(pivots[0])+”\nR1: “+DoubleToStr(pivots[1]);
string pivotText=GetPivotDirection(pips)+” “+GetPivotStr(closestIdx);

DrawLabel(“pivots_”+symbolName,x,y,pivotText,fontSize,fontName,GetPivotColor(closestIdx),tooltip);
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawMAColumn(string symbolName,int x,int y,string text,int fontSize=8,string fontName=”Calibri”)
{
double ma=iMA(symbolName,MATimeframe,MAPeriod,0,MAMethod,MAAppliedPrice,0);
string tooltip=symbolName+”\n.: “+GetPeriodStr(MATimeframe)+” MA (“+IntegerToString(MAPeriod)+”):.\nCurrent (“+DoubleToStr(ma,1)+”)”;
DrawLabel(“ma_”+symbolName,x,y,GetMAStr(ma),fontSize,fontName,GetMAColor(ma),tooltip);
}
//+——————————————————————+
//| |
//+——————————————————————+
color GetPivotColor(int pivotIdx)
{
if(pivotIdx==0)
return clrWhite;
if(pivotIdx<=3)
return clrGreen;
return clrRed;
}
//+——————————————————————+
//| |
//+——————————————————————+
int GetClosestPivot(double ask,double &pivots[])
{
int idx=0;
double minDistance=1.7976931348623158e+308;
for(int i=0;i<ArraySize(pivots);i++)
{
double dist=MathAbs(ask-pivots[i]);
if(dist<minDistance)
{
minDistance=dist;
idx=i;
}
}
return idx;
}
//+——————————————————————+
//| |
//+——————————————————————+
string GetPivotDirection(double value)
{
if(value>0)
return “Above”;
return “Bellow”;
}
//+——————————————————————+
//| |
//+——————————————————————+
double GetPivotValue(string symbolName,int timeframe)
{
//Pivot point (PP) = (High + Low + Close) / 3
return (iHigh(symbolName,timeframe,1)+iLow(symbolName,timeframe,1)+iClose(symbolName,timeframe,1))/3;
}
//+——————————————————————+
//| |
//+——————————————————————+
double GetPivotResistance(string symbolName,int timeframe,double pivotValue,int resistanceIdx=1)
{
switch(resistanceIdx)
{
case 3:
//Third resistance (R3) = High + 2(PP – Low)
return iHigh(symbolName,timeframe,1) + 2*(pivotValue – iLow(symbolName,timeframe,1));
case 2:
//Second resistance (R2) = PP + (High – Low)
return pivotValue + (iHigh(symbolName,timeframe,1)-iLow(symbolName,timeframe,1));
default:
//First resistance (R1) = (2 x PP) – Low
return (2*pivotValue) – iLow(symbolName,timeframe,1);
}
}
//+——————————————————————+
//| |
//+——————————————————————+
double GetPivotSupport(string symbolName,int timeframe,double pivotValue,int supportIdx=1)
{
switch(supportIdx)
{
case 3:
//Third support (S3) = Low – 2(High – PP)
return iLow(symbolName,timeframe,1) – 2*(iHigh(symbolName,timeframe,1)-pivotValue);
case 2:
//Second support (S2) = PP – (High – Low)
return pivotValue – (iHigh(symbolName,timeframe,1) – iLow(symbolName,timeframe,1));
default:
//First support (S1) = (2 x PP) – High
return (2*pivotValue) – iHigh(symbolName,timeframe,1);
}
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawVolumeColumn(string symbolName,int x,int y,string text,int fontSize=8,string fontName=”Calibri”)
{
long volume=iVolume(symbolName,VolumeTimeframe,0);
double volAvg=(double)getAvgVolume(symbolName,VolumePeriod);
if(volAvg==0) volAvg=1;
double volPercent=(volume/volAvg)*100;
string tooltip=symbolName+”\n.: “+GetPeriodStr(VolumeTimeframe)+” Volume (“+IntegerToString(VolumePeriod)+”):.\nCurrent (“+DoubleToStr(volume,0)+”)\nAverage (“+DoubleToStr(volAvg,0)+”)”;

DrawLabel(“vol”+symbolName,x,y,DoubleToStr(volPercent,2)+”%”,fontSize,fontName,GetPercentColor(volPercent),tooltip);
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawRangeColumn(string symbolName,int x,int y,string text,int fontSize=8,string fontName=”Calibri”)
{
double atr=0;
double point=getPoint(symbolName);
double modifier=getModifier(symbolName);

if(point>0) atr=(NormalizeDouble(iATR(symbolName,AtrTimeframe,AtrPeriod,0)/point,0))/modifier;
if(atr==0) atr=1;
double range=getRange(symbolName,AtrTimeframe)/modifier;
double rangePercent=(range/atr)*100;
string tooltip=symbolName+”\n.: “+GetPeriodStr(AtrTimeframe)+” ATR (“+IntegerToString(AtrPeriod)+”):.\nCurrent (“+DoubleToStr(range,1)+”)\nAverage (“+DoubleToStr(atr,1)+”)”;

DrawLabel(“atr_”+symbolName,x,y,DoubleToStr(rangePercent,1)+”%”,fontSize,fontName,GetPercentColor(rangePercent),tooltip);
}
//+——————————————————————+
//| |
//+——————————————————————+
color GetRsiColor(double value)
{
if(value>=RsiUpperLevel)
return clrGreen;
if(value<=RsiLowerLevel)
return clrRed;
return clrWhite;
}
//+——————————————————————+
//| |
//+——————————————————————+
color GetMAColor(double value)
{
if(Ask<=value)
return clrGreen;
else
return clrRed;
}
//+——————————————————————+
//| |
//+——————————————————————+
string GetMAStr(double value)
{
if(Ask<=value)
return “down”;
else
return “up”;
}
//+——————————————————————+
//| |
//+——————————————————————+
color GetStochColor(double value)
{
if(value>=StochUpperLevel)
return clrGreen;
if(value<=StochLowerLevel)
return clrRed;
return clrWhite;
}
//+——————————————————————+
//| |
//+——————————————————————+
color GetPercentColor(double value)
{
if(value<=25)
return clrWhite;
if(value<=50)
return clrGreen;
if(value<=75)
return clrYellow;
if(value<=100)
return clrRed;
return clrPurple;
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawSymbolColumn(string symbolName,int x,int y,string text,int fontSize=8,string fontName=”Calibri”)
{
DrawLabel(“lbl_”+symbolName,x,y,text,fontSize,fontName,clrWhite,symbolName);
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawHeader()
{
string objName=”Header”;
int numColumns=(SymbolsTotal(true)/ColumnHeight)+1;
int i=0;
do
{
int x=(GUIXOffset+GUIHeaderXOffset)+(NumVisibleColumns()*GUIColOffset)*i;
int y=GUIYOffset+GUIHeaderYOffset;
string n=IntegerToString(i);

DrawLabel(objName+”name”+n,x,y,”Name”,FontSize,FontName,clrWhite,”Name”);
DrawHorizontalLine(objName+”namehline”+n,x,y,15);

if(ShowPrice)
{
DrawLabel(objName+”price”+n,x+=GUIColOffset,y,”Price”,FontSize,FontName,clrWhite,”Price”);
DrawHorizontalLine(objName+”pricehline”+n,x,y,15);
}
if(ShowSpread)
{
DrawLabel(objName+”spread”+n,x+=GUIColOffset,y,”Spread”,FontSize,FontName,clrWhite,”Spread”);
DrawHorizontalLine(objName+”spreadhline”+n,x,y,15);
}
if(ShowATR)
{
DrawLabel(objName+”range”+n,x+=GUIColOffset,y,”ATR (“+GetPeriodStr(AtrTimeframe)+”)”,FontSize,FontName,clrWhite,”Range”);
DrawHorizontalLine(objName+”rangehline”+n,x,y,15);
}
if(ShowVolume)
{
DrawLabel(objName+”curvolume”+n,x+=GUIColOffset,y,”Vol (“+GetPeriodStr(VolumeTimeframe)+”)”,FontSize,FontName,clrWhite,”Volume”);
DrawHorizontalLine(objName+”volhline”+n,x,y,15);
}
if(ShowRsi)
{
DrawLabel(objName+”rsi”+n,x+=GUIColOffset,y,”RSI (“+GetPeriodStr(RsiTimeframe)+”)”,FontSize,FontName,clrWhite,”Pivots”);
DrawHorizontalLine(objName+”rsihline”+n,x,y,15);
}
if(ShowStoch)
{
DrawLabel(objName+”stoch”+n,x+=GUIColOffset,y,”Stoch (“+GetPeriodStr(StochTimeframe)+”)”,FontSize,FontName,clrWhite,”Stochastic”);
DrawHorizontalLine(objName+”stochhline”+n,x,y,15);
}
if(ShowAdx)
{
DrawLabel(objName+”,adx”+n,x+=GUIColOffset,y,”ADX (“+GetPeriodStr(AdxTimeframe)+”)”,FontSize,FontName,clrWhite,”ADX”);
DrawHorizontalLine(objName+”adxhline”+n,x,y,15);
}

if(ShowPivots)
{
DrawLabel(objName+”pivots”+n,x+=GUIColOffset,y,”Pivots”,FontSize,FontName,clrWhite,”Pivots”);
DrawHorizontalLine(objName+”pvotshline”+n,x,y,15);
}

if(ShowMA)
{
DrawLabel(objName+”ma”+n,x+=GUIColOffset,y,”MA”,FontSize,FontName,clrWhite,”MA”);
DrawHorizontalLine(objName+”maline”+n,x,y,15);
}
i++;
}
while(i<numColumns);
}
//+——————————————————————+
//| |
//+——————————————————————+
int NumVisibleColumns()
{
int x=1;
if(ShowPrice)
{
x++;
}
if(ShowSpread)
{
x++;
}
if(ShowATR)
{
x++;
}
if(ShowVolume)
{
x++;
}
if(ShowRsi)
{
x++;
}
if(ShowStoch)
{
x++;
}
if(ShowAdx)
{
x++;
}
if(ShowPivots)
{
x++;
}
if(ShowMA)
{
x++;
}
return x;
}
//+——————————————————————+
//| |
//+——————————————————————+
void DrawHorizontalLine(string objName,int x,int y,int length=250)
{
string line;
for(int i=0;i<length;i++)
line += “_”;

DrawLabel(objName+”1″,x,y,line,FontSize,FontName,clrWhite,””);
//DrawLabel(objName+”2″,x+380,y,line,FontSize,FontName,clrWhite,””);
}
//+——————————————————————+
int periodToMinutes(int period)
{
int i;
static int _per[]={1,2,3,4,5,6,10,12,15,20,30,60,120,180,240,360,480,720,1440,10080,43200,0×4001,0x4002,0x4003,0x4004,0x4006,0x4008,0x400c,0x4018,0x8001,0xc001};
static int _min[]={1,2,3,4,5,6,10,12,15,20,30,60,120,180,240,360,480,720,1440,10080,43200};
//—
if(period==PERIOD_CURRENT)
period=Period();
for(i=0;i<20;i++) if(period==_per[i]) break;
return(_min[i]);
}
//+——————————————————————+
datetime iTime(int period)
{
datetime times[];
if(CopyTime(Symbol(),period,0,1,times)<=0)
return(TimeLocal());
return(times[0]);
}
//+——————————————————————+
string getTime(int times,color &theColor)
{
string stime=””;
int seconds;
int minutes;
int hours;

if(times<0)
{
theColor=clrRed;
times=(int)fabs(times);
}
else if(times>0)
{
theColor=clrYellow;
}

seconds = (times%60);
hours = (times-times%3600)/3600;
minutes = (times-seconds)/60-hours*60;
//—
if(hours>0)
if(minutes<10)
stime = stime+(string)hours+”:0″;
else stime = stime+(string)hours+”:”;
stime=stime+(string)minutes;
if(seconds<10)
stime=stime+”:0″+(string)seconds;
else stime=stime+”:”+(string)seconds;
return(stime);
}
//+——————————————————————+
string GetPivotStr(int pivotIdx)
{
switch(pivotIdx)
{
case 1:
return “R1”;
case 2:
return “R2”;
case 3:
return “R3”;
case 4:
return “S1”;
case 5:
return “S2”;
case 6:
return “S3”;
default:
return “PP”;
}
}
//+——————————————————————+
//| |
//+——————————————————————+
string GetPeriodStr(int period)
{
string TMz=””;
switch(period)
{
case 1: TMz = “M1”; break;
case 2: TMz = “M2”; break;
case 3: TMz = “M3”; break;
case 4: TMz = “M4”; break;
case 5: TMz = “M5”; break;
case 6: TMz = “M6”; break;
case 7: TMz = “M7”; break;
case 8: TMz = “M8”; break;
case 9: TMz = “M9”; break;
case 10: TMz = “M10”; break;
case 11: TMz = “M11”; break;
case 12: TMz = “M12”; break;
case 13: TMz = “M13”; break;
case 14: TMz = “M14”; break;
case 15: TMz = “M15”; break;
case 20: TMz = “M20”; break;
case 25: TMz = “M25”; break;
case 30: TMz = “M30”; break;
case 40: TMz = “M40”; break;
case 45: TMz = “M45”; break;
case 50: TMz = “M50”; break;
case 60: TMz = “H1”; break;
case 120: TMz = “H2”; break;
case 180: TMz = “H3”; break;
case 240: TMz = “H4”; break;
case 300: TMz = “H5”; break;
case 360: TMz = “H6”; break;
case 420: TMz = “H7”; break;
case 480: TMz = “H8”; break;
case 540: TMz = “H9”; break;
case 600: TMz = “H10”; break;
case 660: TMz = “H11”; break;
case 720: TMz = “H12”; break;
case 1440: TMz = “D1”; break;
case 10080: TMz = “W1”; break;
case 43200: TMz = “M1″; break;
}
return TMz;
}
//+——————————————————————+
//+——————————————————————+
//| Create a trend line by the given coordinates |
//+——————————————————————+
bool TrendCreate(const long chart_ID=0, // chart’s ID
const string name=”TrendLine”, // line name
const int sub_window=0, // subwindow index
datetime time1=0, // first point time
double price1=0, // first point price
datetime time2=0, // second point time
double price2=0, // second point price
const color clr=clrRed, // line color
const ENUM_LINE_STYLE style=STYLE_SOLID, // line style
const int width=1, // line width
const bool back=false, // in the background
const bool selection=true, // highlight to move
const bool ray_right=false, // line’s continuation to the right
const bool hidden=true, // hidden in the object list
const long z_order=0) // priority for mouse click
{
//— set anchor points’ coordinates if they are not set
ChangeTrendEmptyPoints(time1,price1,time2,price2);
//— reset the error value
ResetLastError();
//— create a trend line by the given coordinates
if(!ObjectCreate(chart_ID,name,OBJ_TREND,sub_window,time1,price1,time2,price2))
{
Print(__FUNCTION__,
“: failed to create a trend line! Error code = “,GetLastError());
return(false);
}
//— set line color
ObjectSetInteger(chart_ID,name,OBJPROP_COLOR,clr);
//— set line display style
ObjectSetInteger(chart_ID,name,OBJPROP_STYLE,style);
//— set line width
ObjectSetInteger(chart_ID,name,OBJPROP_WIDTH,width);
//— display in the foreground (false) or background (true)
ObjectSetInteger(chart_ID,name,OBJPROP_BACK,back);
//— enable (true) or disable (false) the mode of moving the line by mouse
//— when creating a graphical object using ObjectCreate function, the object cannot be
//— highlighted and moved by default. Inside this method, selection parameter
//— is true by default making it possible to highlight and move the object
ObjectSetInteger(chart_ID,name,OBJPROP_SELECTABLE,selection);
ObjectSetInteger(chart_ID,name,OBJPROP_SELECTED,selection);
//— enable (true) or disable (false) the mode of continuation of the line’s display to the right
ObjectSetInteger(chart_ID,name,OBJPROP_RAY_RIGHT,ray_right);
//— hide (true) or display (false) graphical object name in the object list
ObjectSetInteger(chart_ID,name,OBJPROP_HIDDEN,hidden);
//— set the priority for receiving the event of a mouse click in the chart
ObjectSetInteger(chart_ID,name,OBJPROP_ZORDER,z_order);
//— successful execution
return(true);
}
//+——————————————————————+
//| Check the values of trend line’s anchor points and set default |
//| values for empty ones |
//+——————————————————————+
void ChangeTrendEmptyPoints(datetime &time1,double &price1,
datetime &time2,double &price2)
{
//— if the first point’s time is not set, it will be on the current bar
if(!time1)
time1=TimeCurrent();
//— if the first point’s price is not set, it will have Bid value
if(!price1)
price1=SymbolInfoDouble(Symbol(),SYMBOL_BID);
//— if the second point’s time is not set, it is located 9 bars left from the second one
if(!time2)
{
//— array for receiving the open time of the last 10 bars
datetime temp[10];
CopyTime(Symbol(),Period(),time1,10,temp);
//— set the second point 9 bars left from the first one
time2=temp[0];
}
//— if the second point’s price is not set, it is equal to the first point’s one
if(!price2)
price2=price1;
}
//+——————————————————————+
