order_graphic_tool_v5

//+——————————————————————+
//| 7:26 AM 7/10/2016 Order_Manager.mq4 |
//| Copyright 2016-17, WHRoeder@yahoo.com |
//+——————————————————————+
#property copyright “Copyright © 2016-17, WHRoeder@yahoo.com”
#property link “mailto:WHRoeder@yahoo.com”
#property version “1.05”
/* V5 Changes
* One Cancels Other (OCO.) Two opposite pending orders, when first filled,
* other is deleted, (if enabled.)
* Generalization of PIP for metals and exotics.
* Trades are shown like the tester does, or when closed orders are dragged onto
* the chart (if enabled.)
*
* v4 Changes
* Build 970 broke code. MQL4: Fixed generating events related to mouse movement
* and mouse button pressing over objects of OBJ_LABEL and OBJ_TEXT types.
* Previously, the events were generated incorrectly if they were within other
* objects of OBJ_RECTANGLE_LABEL and OBJ_RECTANGLE types.
* The delay between the indicator and the EA means following price was hit
* and miss, with a blank alert.
* So I refactored it in to one EA. Line count went from 1818 to 642
*
* v3 Published: 2015.09.10 10:27
* ‘Money Manager Graphic Tool’ indicator by ‘takycard’ for MetaTrader 4 in
* the MQL5 Code Base — https://www.mql5.com/en/code/13804
*/

#property strict
/* +————————————————————–+
| [] : PIP = 0.00010 |
| Risk : 1.00% = 53.33 USD / Balance 5333.34 USD |
| Ratio : no TP [1|2|3|4] |
| SL : [40.1 pips 50.76 USD] |
| TP : no TP |
| Lot Size Max : 0.13 |
| –SandBox-/-OpenOrder—————- |
| Risk [+-]: 1.00% = 52.73 USD / Balance 5272.81 USD |
| Lot Size [+-]: 0.14 |
| SL : [40.1 pips 50.76 USD] |
| TP : no TP |
| Off Show TP Line On Show SL Line Yes Follow price |
| [__Order Buy 0.14 lot__] [Close] |
| Min Lot:0.01 / Max Lot:1000.0 / Step:0.01 / SL TP limit:0.0 |
+————————————————————–+ */
enum Priority{ Priority_None, Priority_Lines, Priority_Box, Priority_Buttons };

extern string BuyLine = “B”; //Key to Create a Buy Line
extern string SellLine = “S”; //Key to Create a Sell Line
extern string CloseGUI = “C”; //Key to Close GUI
extern double InitialPercent = 1.0; //Percentage Initial Risk
extern color ColorEntry = clrLime; //Color of the entry line
extern color ColorSL = clrRed; //Color of the SL line
extern color ColorTP = clrGold; //Color of the TP line
extern ENUM_LINE_STYLE
LineStyle = STYLE_SOLID; //Style of Lines
extern int LineWidth = 2; //Width of the line
extern color ColorBox = clrBlack; //Box background color
extern color ColorText = clrWhite; //Box text color
enum Money{ Balance, Equity };
extern bool RiskBasis = Balance; //Risk basis
extern double CommissionPerLot = 0.00; //Commission charged per lot.
extern bool CreateSL = true; //Create a Stop Loss line
extern bool CreateTP = false; //Create a Take Profit line
extern double TpRatio = 2.0; //Default TP Ratio
extern bool TransparentBox = false; //Transparent dialog box
extern int MagicNumber = 951357; //Magic Number
extern bool OCOEnabled = true; //One cancels other
extern bool ShowTrades = true; //Show Trades
extern bool AlertClosedTrades = false; //Alert Closed Trades
// updated first tick
int digitsLots;
int digitsPip;
double lotStep;
double maximumLot;
double minimumLot;
double pips2dbl;
double stopLevel;
double tickSize;
double tickValue;
// updated OnChartEvent or perTick
double defaultSLpips = 30; // Default SL in Pips
double direction = 0; // Buy=+1/Sell=-1/GUI not visible=0
double entryPrice, slPrice, tpPrice;
bool fixedLotsize;
bool followingPrice;
double mousePrice; // Price under mouse.
int orderType; // OP_BUY
int orgX = 15; // X start
int orgY = 15; // Y start
double sandboxLotsize;
double sandboxPercent;
bool tpRatioFixed;
enum Trade_Operation{
TO_BUY, TO_SELL, TO_BUYLIMIT, TO_SELLLIMIT, TO_BUYSTOP, TO_SELLSTOP,
TO_BALANCE, ///< (6) May occur in history pool.
TO_CREDIT}; ///< (7) May occur in history pool.
const Trade_Operation MKT_FIRST = TO_BUY; ///< (0) OP_BUY.
const Trade_Operation MKT_LAST = TO_SELL; ///< (1) OP_SELL.
const Trade_Operation PND_FIRST = TO_BUYLIMIT;///< (2) OP_BUYLIMIT.
const Trade_Operation PND_LAST = TO_SELLSTOP;///< (5) OP_SELLSTOP.
const int MKT_COUNT = 2; ///< (2) [OP_BUY-OP_SELL]
//+——————————————————————+
//| Initialization |
//+——————————————————————+
bool firstTick, firstTimer;
int OnInit(){
if(CommissionPerLot < 0) return INIT_PARAMETERS_INCORRECT;
if(InitialPercent <= 0.1) return INIT_PARAMETERS_INCORRECT;
firstTick = true; firstTimer = true; OnInit2();
ChartSetInteger(0, CHART_EVENT_MOUSE_MOVE, 1); // mousePrice
if(!EventSetTimer(1) ) Alert(StringFormat(“EST:%i”, _LastError) );
return INIT_SUCCEEDED;
}
//+——————————————————————+
//| Custom indicator timer function |
//+——————————————————————+
void OnTimer(void){
if(ShowTrades){
for(int iPos = OrdersHistoryTotal(); iPos > 0;){ –iPos;
if(select_order(iPos, SELECT_BY_POS, MODE_HISTORY) )
create_trades(AlertClosedTrades && !firstTimer);
}
} // ShowTrades
firstTimer = false;
}
void OnInit2(void){
// Must be connected to account server.
lotStep = MarketInfo(_Symbol, MODE_LOTSTEP);
digitsLots = digits_in(lotStep);
maximumLot = MarketInfo(_Symbol, MODE_MAXLOT);
minimumLot = MarketInfo(_Symbol, MODE_MINLOT);
stopLevel = MarketInfo(_Symbol, MODE_STOPLEVEL);
tickSize = MarketInfo(_Symbol, MODE_TICKSIZE);

/* Don’t try to use any price or server related functions in
* OnInit as there may be no connection/chart yet:
* Terminal starts.
* indicators/EAs are loaded.
* OnInit is called.
* For indicators OnCalculate is called with any existing history.
* Human may have to enter password, connection to server begins.
* New history is received, OnCalculate called again.
* New tick is received, OnCalculate/OnTick is called.
* Now TickValue, TimeCurrent and prices are valid.
*/
tickValue = MarketInfo(_Symbol, MODE_TICKVALUE);
//if(tickValue != 0){ // handle metals and exotics like USDMXN/USDZAR
// firstTick = false; double dVpL = tickValue / tickSize;
// pips2dbl = tickSize; digitsPip = 0;
// while(dVpL * pips2dbl < 5){ pips2dbl *= 10; ++digitsPip; }
//}else{
// digitsPip = Digits % 2;
// pips2dbl = digitsPip == 0 ? Point : 10.0 * Point;
//}

if(tickValue != 0){ // handle metals and exotics like USDMXN/USDZAR
firstTick = false; double dVpL = tickValue / tickSize;
pips2dbl = tickSize; digitsPip = 0;
}
if (Digits % 2 == 1) { // DE30=1/JPY=3/EURUSD=5 forum.mql4.com/43064#515262
//pips2dbl = Point*10; digitsPip = 1;
pips2dbl *= 10; digitsPip = 1;
} else {
pips2dbl = Point; //digitsPip = 0;
}

double minGapPips = stopLevel * Point / pips2dbl;
if(defaultSLpips < minGapPips) defaultSLpips = minGapPips;
}
void OnTick(){
tickValue = MarketInfo(_Symbol, MODE_TICKVALUE); // Changes per tick.
if(firstTick) OnInit2();
if(direction != 0) move_entry(entryPrice); // GUI visible
if(OCOEnabled){
enum TriState { TS_ON, TS_OFF, TS_UNKOWN };
static TriState ocoState = TS_UNKOWN; // No Alert on start up
if(ocoState == TS_ON){
if( find_ticket(TO_BUY) != EMPTY){
/*void*/order_delete(TO_SELLSTOP); ocoState = TS_OFF;
}else if(find_ticket(TO_SELL) != EMPTY){
/*void*/order_delete(TO_BUYSTOP); ocoState = TS_OFF;
} }
if(find_ticket(TO_BUYSTOP) != EMPTY && find_ticket(TO_SELLSTOP) != EMPTY){
if(ocoState == TS_OFF) Alert(_Symbol+” OCO active”);
ocoState = TS_ON;
}else
ocoState = TS_OFF;
}
} // OnTick
//+——————————————————————+
//| Expert deinitialization function |
//+——————————————————————+
void OnDeinit(const int reason){ EventKillTimer();
delete_gui(); direction = 0; // GUI not visible
if(ShowTrades) delete_trades();
}
//+——————————————————————+
//| ChartEvent function |
//+——————————————————————+
void OnChartEvent(const int id,
const long &lparam,
const double &dparam,
const string &sparam){
if( id == CHARTEVENT_KEYDOWN){
if( lparam == StringGetChar(BuyLine, 0) ) begin_gui(+1);
else if(lparam == StringGetChar(SellLine, 0)) begin_gui(-1);
else if(lparam == StringGetChar(CloseGUI, 0) ){
delete_gui(); direction = 0; // GUI not visible
}
} // CHARTEVENT_KEYDOWN
else if(id == CHARTEVENT_MOUSE_MOVE){
datetime dt; int sub_win;
ChartXYToTimePrice(0, (int)lparam, (int)dparam, sub_win, dt, mousePrice);
}
else if(direction == 0) // GUI not visible; Ignore click,
return; // Including a double click on order button.
else if(id == CHARTEVENT_OBJECT_DRAG){
if( sparam == “MMGT_RecMov”){
orgX = (int) ObjectGet(“MMGT_RecMov”, OBJPROP_XDISTANCE);
orgY = (int) ObjectGet(“MMGT_RecMov”, OBJPROP_YDISTANCE);
create_gui();
}
else if(sparam == “MMGT_Entry_Line”){
followingPrice = false;
move_entry(ObjectGet(“MMGT_Entry_Line”, OBJPROP_PRICE1) );
}
else if(sparam == “MMGT_TP_Line”){
tpRatioFixed = false;
move_tp(ObjectGet(“MMGT_TP_Line”, OBJPROP_PRICE1) );
}
else if(sparam == “MMGT_SL_Line”){
move_sl(ObjectGet(“MMGT_SL_Line”, OBJPROP_PRICE1) );
}
} // Drag
else if(id == CHARTEVENT_OBJECT_CLICK){
if( sparam == “MMGT_RiskSizeButtonPlus”){
sandboxPercent = round_nearest(sandboxPercent + 0.1, 0.1);
fixedLotsize = false; PlaySound(“tick.wav”); create_gui();
}
else if(sparam == “MMGT_RiskSizeButtonMinus”){
sandboxPercent = round_nearest(sandboxPercent – 0.1, 0.1);
fixedLotsize = false; PlaySound(“tick.wav”); create_gui();
}
else if(sparam == “MMGT_LotSizeButtonPlus”){
sandboxLotsize = MathMax(minimumLot,
MathMin(maximumLot, sandboxLotsize + lotStep) );
fixedLotsize = true;
PlaySound(“tick.wav”); create_gui();
}
else if(sparam == “MMGT_LotSizeButtonMinus”){
sandboxLotsize = MathMax(minimumLot,
MathMin(maximumLot, sandboxLotsize – lotStep) );
fixedLotsize = true;
PlaySound(“tick.wav”); create_gui();
}
else if(sparam == “MMGT_RatioButton1”){
TpRatio = 1.0; tpRatioFixed = true;
PlaySound(“tick.wav”); move_tp(tpPrice);
}
else if(sparam == “MMGT_RatioButton2”){
TpRatio = 2.0; tpRatioFixed = true;
PlaySound(“tick.wav”); move_tp(tpPrice);
}
else if(sparam == “MMGT_RatioButton3”){
TpRatio = 3.0; tpRatioFixed = true;
PlaySound(“tick.wav”); move_tp(tpPrice);
}
else if(sparam == “MMGT_RatioButton4”){
TpRatio = 4.0; tpRatioFixed = true;
PlaySound(“tick.wav”); move_tp(tpPrice);
}
else if(sparam == “MMGT_Close”){
PlaySound(“tick.wav”); delete_gui();
direction = 0; // GUI not visible
}
else if(sparam == “MMGT_TPButton”){
CreateTP = (!CreateTP);
PlaySound(“tick.wav”); move_tp(tpPrice);
}
else if(sparam == “MMGT_SLButton”){
CreateSL = (!CreateSL);
if(!CreateSL) fixedLotsize = true; // Use sandboxLotsize.
PlaySound(“tick.wav”); move_sl(slPrice);
}
else if(sparam == “MMGT_FollowButton”){
followingPrice = (!followingPrice);
PlaySound(“tick.wav”); move_entry(entryPrice);
}
else if(sparam == “MMGT_OrderButton”){
PlaySound(“tick.wav”);
if(!newOrder() )
ObjectSetInteger(0, “MMGT_OrderButton”, OBJPROP_STATE, false);
else{
delete_gui(); direction = 0; // GUI not visible
} }
} // CHARTEVENT_OBJECT_CLICK
} // OnChartEvent
//+——————————————————————+
//| GUI |
//+——————————————————————+
void begin_gui(double d){
int iLeft,iRight; double top,bot; GetChartLimits(iLeft, iRight, top, bot);
double onePct = (top – bot) * 0.01; bot += onePct; top -= onePct;
if(defaultSLpips < 4.0 * onePct / pips2dbl) // USDMXN 4%=600 pips.
defaultSLpips = 4.0 * onePct / pips2dbl; // No overlap entry_text/sL_line

direction = d;
followingPrice = mousePrice < bot || mousePrice > top; // If Outside chart,
if(followingPrice) entryPrice = d > 0 ? Ask : Bid; // follow.
else entryPrice = mousePrice; // Inside chart.
tpRatioFixed = true;
slPrice = entryPrice -direction* defaultSLpips * pips2dbl;
tpPrice = entryPrice +direction* defaultSLpips * pips2dbl * TpRatio;
sandboxPercent = InitialPercent;
sandboxLotsize = minimumLot; fixedLotsize = !CreateSL;
move_entry(entryPrice);
}
void move_entry(double price){
if(followingPrice){
orderType = direction> 0 ? OP_BUY : OP_SELL;
price = direction> 0 ? Ask : Bid;
}
else{
double minGap = stopLevel * Point;
double upper = Ask + minGap;
double lower = Bid – minGap;
if(price > (upper+lower)/2.0){
orderType = direction> 0 ? OP_BUYSTOP : OP_SELLLIMIT;
if(price < upper) price = upper;
}
else{
orderType = direction> 0 ? OP_BUYLIMIT : OP_SELLSTOP;
if(price > lower) price = lower;
} }
entryPrice = normalize_price(price);
move_sl(slPrice);
}
void move_sl(double price){
double minGap = stopLevel * Point;
if( (entryPrice – price)*direction < minGap)
price = entryPrice -direction * minGap;
slPrice = normalize_price(price, -direction);
move_tp(tpPrice);
}
void move_tp(double price){
double minGap = stopLevel * Point;
if(tpRatioFixed)
price = entryPrice + (entryPrice – slPrice) * TpRatio;
if( (price – entryPrice)*direction < minGap)
price = entryPrice +direction * minGap;
tpPrice = normalize_price(price, +direction);
create_gui();
}
void create_gui(void){
double sl = MathAbs(slPrice – entryPrice),
slPips = (slPrice – entryPrice) / pips2dbl,
tp = MathAbs(tpPrice – entryPrice),
tpPips = (tpPrice – entryPrice) / pips2dbl;
defaultSLpips = sl / pips2dbl;
// RISK = Account Balance * percent/100
// RISK = OrderLots * (|OrderOpenPrice – OrderStopLoss| * DeltaValuePerlot
// + CommissionPerLot)
// (Note OOP-OSL includes the SPREAD)
double dVpL = tickValue / tickSize; // DeltaValuePerlot

string USD = AccountInfoString(ACCOUNT_CURRENCY);
string balance = RiskBasis == Balance ? “Balance” : “Equity”;
double money = AccountInfoDouble(RiskBasis == Balance ? ACCOUNT_BALANCE
: ACCOUNT_EQUITY);

double risk = money * InitialPercent / 100.0;
double maxLots = normalize_lots( risk / (sl * dVpL + CommissionPerLot) ); // div 0
// Percentage
double maxBet = maxLots * (sl * dVpL + CommissionPerLot);
double maxWin = maxLots * tp * dVpL;

double sbRisk = money * sandboxPercent / 100.0;
if(!fixedLotsize)
sandboxLotsize = normalize_lots(sbRisk / (sl * dVpL + CommissionPerLot) );
double sbBet = sandboxLotsize * (sl * dVpL + CommissionPerLot);
if(fixedLotsize){
sandboxPercent = round_nearest(sbBet / money * 100.0, 0.01);
sbRisk = money * sandboxPercent / 100.0;;
}
double sbWin = sandboxLotsize * tp * dVpL;

string text1 = StringFormat(
“Risk : %.1f%% = %.2f %s / %s %.2f %s”,
InitialPercent, risk, USD, balance, money, USD);
string text7 = StringFormat(
“Risk : %.2f%% = %.2f %s / %s %.2f %s”,
sandboxPercent, sbRisk, USD, balance, money, USD);

string text2 = “Ratio : no TP”;
string text4 = “TP : no TP”;
string text10 = “TP : no TP”;
if(CreateTP){
if(!CreateSL) text2 = “Ratio : no SL”;
else{ text2 = StringFormat(“Ratio : 1:%.2f”,
tp / MathMax(Point, sl) );
text4 = StringFormat(“TP : [%s pips %.2f %s]”,
pips_as_string(tpPips), maxWin, USD);
text10 = StringFormat(“TP : [%s pips %.2f %s]”,
pips_as_string(tpPips), sbWin, USD);
} }
string text3 = “SL : no SL”; color color3 = ColorText;
string text5 = “Lot Size Max : no SL”; color color5 = clrYellow;
string text9 = “SL : no SL”;
string text8 = StringFormat(“Lot Size : %s”,
lots_as_string(sandboxLotsize) );
color color8 = sandboxLotsize < minimumLot
|| sandboxLotsize > maximumLot ? clrRed : clrYellow;
if(CreateSL){
text3 = StringFormat(“SL : [%s pips %.2f %s]”,
pips_as_string(slPips), maxBet, USD);
text9 = StringFormat(“SL : [%s pips %.2f %s]”,
pips_as_string(slPips), sbBet, USD);
if(sl < (Ask – Bid) *2.0) color3 = clrRed;
text5 = StringFormat(“Lot Size Max : %s”, lots_as_string(maxLots) );
// Percentage
color5 = maxLots < minimumLot
|| maxLots > maximumLot ? clrRed : ColorText;
if(sandboxLotsize <= maxLots) color8 = color5;
/* MaximumLot Broker limits
maximumLot = MarketInfo(_Symbol, MODE_MAXLOT);
minimumLot = MarketInfo(_Symbol, MODE_MINLOT);
sandboxLotsize <= maxLots Percentage Risk
tbd Margin Call
*/
}
// Make the GUI
delete_gui();

// Create the lines in selectable order, entry, tp, SL!.
double pips = (entryPrice – Bid) / pips2dbl;
string text = StringFormat(“%s / %s Pips from actual price”,
price_as_string(entryPrice), pips_as_string(pips) );
create_hLine(“MMGT_Entry_Line”, entryPrice, ColorEntry);
create_text( “MMGT_Entry_Text”, entryPrice, text, ColorEntry);

string bs = direction > 0 ? “Buy” : “Sell”;
if(CreateTP){
pips = (tpPrice – entryPrice) / pips2dbl;
text = StringFormat(“TP at %s / %s Pips from %s”,
price_as_string(slPrice), pips_as_string(pips), bs);
create_hLine(“MMGT_TP_Line”, tpPrice, ColorTP);
create_text( “MMGT_TP_Text”, tpPrice, text, ColorTP);
}
if(CreateSL){
pips = (slPrice – entryPrice) / pips2dbl;
text = StringFormat(“SL at %s / %s Pips from %s”,
price_as_string(slPrice), pips_as_string(pips), bs);
create_hLine(“MMGT_SL_Line”, slPrice, ColorSL);
create_text( “MMGT_SL_Text”, slPrice, text, ColorSL);
}
if(!TransparentBox){
create_rect(“MMGT_RectLabel”, -10, -10, 480, 240);
// Default tip
ObjectSetString(0,”MMGT_RectLabel”, OBJPROP_TOOLTIP, WindowExpertName() );
}
string text0 = StringFormat(
” : PIP = %s”, price_as_string(pips2dbl) );
create_label(“MMGT_Line0”, 0, -5, text0, text0);

create_rect(“MMGT_RecMov”, 0, 0, 10, 10, 3);
ObjectSetInteger(0, “MMGT_RecMov”, OBJPROP_SELECTABLE, true);
ObjectSetInteger(0, “MMGT_RecMov”, OBJPROP_SELECTED, true);
ObjectSetInteger(0, “MMGT_RecMov”, OBJPROP_ZORDER, Priority_Buttons);

text = StringFormat(“Risk %% = Risk %s / Account Size”, USD);
create_label(“MMGT_Line1”, 0, 10, text1, text);
create_label(“MMGT_Line2”, 0, 25, text2, “TP:SL Ratio”);
button_create(“MMGT_RatioButton1”, 180, 27, 12, 12,
“1”, “ratio 1:1”, clrNONE, 8);
button_create(“MMGT_RatioButton2”, 195, 27, 12, 12,
“2”, “ratio 1:2”, clrNONE, 8);
button_create(“MMGT_RatioButton3”, 210, 27, 12, 12,
“3”, “ratio 1:3”, clrNONE, 8);
button_create(“MMGT_RatioButton4”, 225, 27, 12, 12,
“4”, “ratio 1:4”, clrNONE, 8);
create_label(“MMGT_Line3”, 0, 40, text3, “SL pips & value”, color3);
create_label(“MMGT_Line4”, 0, 55, text4, “TP pips & value”);
create_label(“MMGT_Line5”, 0, 70, text5, “Lot Size Max”, color5);
create_label(“MMGT_Line6”, 0, 85,
“–SandBox-/-OpenOrder———————“,
“SandBox Section”);
create_label(“MMGT_Line7”, 0, 100, text7, “Change the risk”);
button_create(“MMGT_RiskSizeButtonPlus”, 80, 102, 10, 10,
“+”, “increase the risk”);
if(sandboxPercent > 0.1)
button_create(“MMGT_RiskSizeButtonMinus”, 90, 102, 10, 10,
“-“, “decrease the risk”);
create_label(“MMGT_Line8”, 0, 115, text8, “Lot Size you want”, color8);
if(sandboxLotsize < maximumLot)
button_create(“MMGT_LotSizeButtonPlus”, 80, 117, 10, 10,
“+”, “increase lot size”);
if(sandboxLotsize > minimumLot)
button_create(“MMGT_LotSizeButtonMinus”, 90, 117, 10, 10,
“-“, “decrease lot size”);
create_label(“MMGT_Line9”, 0, 130, text9, “SL”, color3);
create_label(“MMGT_Line10”, 0, 145, text10, “TP”);
create_label(“MMGT_Line11″, 0, 160,
” Show TP Line Show SL Line Follow price”,
“Tp/SL line On/Off and follow price”);
button_create(“MMGT_TPButton”, 0, 160, 25, 15,
CreateTP ? “On” : “Off”,
“Tp line On/Off”,
CreateTP ? clrGreen : clrRed);
button_create(“MMGT_SLButton”, 150, 160, 25, 15,
CreateSL ? “On” : “Off”,
“TL line On/Off”,
CreateSL ? clrGreen : clrRed);
button_create(“MMGT_FollowButton”, 300, 160, 25, 15,
followingPrice ? “Yes” : “No”,
“Buy/Sell line follows the market”,
followingPrice ? clrGreen : clrRed);
//Line 12 or Order button
if(color8 == clrRed)
create_label(“MMGT_Line12”, 0, 185,
“Lot Size outside limits!”,
“Lot Size outside limits”, clrNONE, 8);
else if(!TerminalInfoInteger(TERMINAL_TRADE_ALLOWED))
create_label(“MMGT_Line12”, 0, 185,
“Check if automated trading is allowed in the terminal settings!”,
“Auto-trading not allowed”, clrNONE, 8);
else{
string opText[] = {“Buy”, “Sell”, “Buy Limit”, “Sell Limit”,
“Buy Stop”, “Sell Stop”};
text = StringFormat(“Order %s %s Lot%s”, opText[orderType],
lots_as_string(sandboxLotsize),
sandboxLotsize > 1.0 ? “s” : “”);
button_create(“MMGT_OrderButton”, 0, 180, 190, 20, text,
“Order used Sandbox parameter”);
}
button_create(“MMGT_Close”, 416, 180, 50, 20, “Close”,
“Close this box and all lines”);
text = StringFormat(
“Min Lot: %.2f / Max Lot: %.2f / Step: %.2f / SL TP limit: %s”,
minimumLot, maximumLot, lotStep,
pips_as_string(stopLevel*Point/pips2dbl, “”) );
create_label(“MMGT_Line13”, 0, 210, text, “Broker limits”, clrNONE, 8);
} // create_gui
void delete_gui(void){ ObjectsDeleteAll(0, “MMGT_”); }
//+——————————————————————+
//| Order button pressed |
//+——————————————————————+
bool newOrder(){ // USDMXN spread = 69.6 pips
RefreshRates();
int slippage = int( (Ask – Bid) * 2.0 / _Point);
if(!CreateTP) tpPrice = 0;
if(!CreateSL) slPrice = 0;
int ticket = OrderSend(_Symbol, orderType, sandboxLotsize, entryPrice,
slippage, slPrice, tpPrice, “OGT”, MagicNumber, 0,
clrNONE);
if(ticket < 0){ // No split www.mql5.com/en/forum/216346#comment_5820584
Alert(errortext(_LastError) );
return false;
}
PlaySound(“ok.wav”);
return true;
}
//+——————————————————————+
//| |
//+——————————————————————+
string errortext(int errorcode){
switch(errorcode){
case 1: return “No result”;
case 2: return “Common error”;
case 3: return “Invalid trade parameters”;
case 4: return “Server busy”;
case 5: return “Old version”;
case 6: return “No connection”;
case 7: return “Not enough rights”;
case 8: return “Too frequent requests”;
case 9: return “Malfunctional trade”;
case 64: return “Account disabled”;
case 65: return “Invalid account”;
case 128: return “Trade timeout”;
case 129: return “Invalid price”;
case 130: return “Invalid stops”;
case 131: return “Invalid trade volume”;
case 132: return “Market is closed”;
case 134: return “Not enough money”;
case 135: return “Price changed”;
case 136: return “Off quotes”;
case 137: return “Broker is busy”;
case 138: return “Requote”;
case 139: return “Order is locked”;

case 141: return “Too many requests”;
case 145: return “Modification denied because order is too close to market”;
case 147: return “Expirations are denied by broker”;
case 148: return “The amount of open and pending orders has reached ”
“the limit set by the broker”;
case 149: return “An attempt to open an order opposite to the existing one ”
“when hedging is disabled”;
case 150: return “An attempt to close an order contravening the FIFO rule”;
default: return StringFormat(“Error %i”, errorcode);
} // switch
//NOTREACHED
}
double normalize_price(double p, double d=0.0){
if(d > 0) return round_up(p, tickSize);
if(d < 0) return round_down(p, tickSize);
return round_nearest(p, tickSize);
}
double normalize_lots(double lots){
return round_down(lots, lotStep);
return lots;
}
string lots_as_string( double lots){ return DoubleToStr(lots, digitsLots); }
string price_as_string(double price){return DoubleToStr(price, _Digits); }
string pips_as_string( double pips, string plusSign=”+”){
return to_signed_fixed(pips, digitsPip, plusSign); }
string to_signed_fixed(double value, int nDecimals, string plusSign=”+”){
if(value < 0.) plusSign = “”;
return plusSign + DoubleToStr(value, nDecimals);
}
string as_string(Trade_Operation op=WRONG_VALUE){
if(op == WRONG_VALUE) op = (Trade_Operation)OrderType();
string TO_xxx = EnumToString(op); // TO_XXX
return StringSubstr(TO_xxx, 3); // XXX
}
bool select_order(int iWhat, int eSelect, int ePool=MODE_TRADES){
if(!OrderSelect(iWhat, eSelect, ePool) ) return false;
if(OrderMagicNumber() != MagicNumber ) return false; // \ Extern
if(OrderSymbol() != _Symbol ) return false; // / variables.
if(ePool != MODE_HISTORY ) return true;
return OrderType() <= OP_SELL; // Avoid cr/bal forum.mql4.com/32363#325360
// Never select canceled orders.
}
int find_ticket(Trade_Operation op, int ePool=MODE_TRADES){
int iPos = ePool == MODE_TRADES ? OrdersTotal() : OrdersHistoryTotal();
while(iPos > 0) if(select_order(–iPos, SELECT_BY_POS, ePool)
&& OrderType() == op ) return OrderTicket();
return EMPTY;
}
bool order_delete(Trade_Operation op){
int ticket = find_ticket(op); if(ticket == EMPTY) return false;
bool result = OrderDelete(ticket);
if(!result) Alert(StringFormat(“OrderDelete(%i):%i”, ticket, _LastError) );
return result;
}
double round_down( double v, double to){ return to * MathFloor(v / to); }
double round_up( double v, double to){ return to * MathCeil( v / to); }
double round_nearest( double v, double to){ return to * MathRound(v / to); }
int digits_in(double d){
int digits = 0;
while(d – int(d) > 1.E-8){ d *= 10.0; ++digits; }
return digits;
}
#define WINDOW_MAIN 0
void GetChartLimits(int&iLeft, int&iRight, double&top, double&bot,int iW=0){
/* MT4 build 445: In the tester (visual mode,) on the first tick, these
* routines return left=100, right=37 (depends on default bar scaling.)
* This is what the chart looks like when you maximize it while it is
* generating the FXT file. On ticks after that, it appears like the
* left/right are correct but the hi/lo are one tick behind the displayed
* chart. On the start of a new bar, the hi/lo can be off when a recent
* extreme drops off but the scale hasn’t resized. I tried calling
* WindowRedraw() first but that did not change results. I don’t know
* about live charts. */
top = WindowPriceMax(iW); iLeft = WindowFirstVisibleBar();
bot = WindowPriceMin(iW); iRight = iLeft-WindowBarsPerChart();
if(top-bot < pips2dbl) top = bot+pips2dbl; // Avoid scroll bug / div0
if(iRight < 0) iRight = 0; // Chart is shifted.
} // GetChartLimits
//+——————————————————————+
//| Create rectangle label |
//+——————————————————————+
void create_rect(string name, int offX, int offY, int width, int height,
int line_width=1){
ObjectCreate(0, name, OBJ_RECTANGLE_LABEL, 0, 0, 0);
ObjectSetInteger(0, name, OBJPROP_XDISTANCE, orgX + offX);
ObjectSetInteger(0, name, OBJPROP_YDISTANCE, orgY + offY);
ObjectSetInteger(0, name, OBJPROP_XSIZE, width);
ObjectSetInteger(0, name, OBJPROP_YSIZE, height);
ObjectSetInteger(0, name, OBJPROP_BGCOLOR, ColorBox);
ObjectSetInteger(0, name, OBJPROP_BORDER_TYPE, BORDER_FLAT);
ObjectSetInteger(0, name, OBJPROP_CORNER, CORNER_LEFT_UPPER);
ObjectSetInteger(0, name, OBJPROP_COLOR, ColorText);
ObjectSetInteger(0, name, OBJPROP_STYLE, STYLE_SOLID);
ObjectSetInteger(0, name, OBJPROP_WIDTH, line_width);
ObjectSetInteger(0, name, OBJPROP_BACK, false);
ObjectSetInteger(0, name, OBJPROP_SELECTABLE, false);
ObjectSetInteger(0, name, OBJPROP_SELECTED, false);
ObjectSetInteger(0, name, OBJPROP_HIDDEN, false);
ObjectSetInteger(0, name, OBJPROP_ZORDER, Priority_Box);
} // create_rect
//+——————————————————————+
//| Create horizontal line |
//+——————————————————————+
void create_hLine(string name, // line name
double hprice, // line price
color clr){ // line color
ObjectCreate(name, OBJ_HLINE, 0, 0, hprice);
ObjectSetInteger(0, name, OBJPROP_COLOR, clr);
ObjectSetInteger(0, name, OBJPROP_STYLE, LineStyle);
ObjectSetInteger(0, name, OBJPROP_WIDTH, LineWidth);
ObjectSetInteger(0, name, OBJPROP_BACK, false);
ObjectSetInteger(0, name, OBJPROP_SELECTABLE, true);
ObjectSetInteger(0, name, OBJPROP_SELECTED, true);
ObjectSetInteger(0, name, OBJPROP_HIDDEN, false);
ObjectSetInteger(0, name, OBJPROP_ZORDER, Priority_Lines);
} // create_hLine
//+——————————————————————+
//| Create button |
//+——————————————————————+
void button_create(string name, int offX, int offY, int width, int height,
string text, string tip, color clr=clrNONE, int font_size=10){
if(clr == clrNONE) clr = ColorText;
ObjectCreate(name, OBJ_BUTTON, 0, 0, 0);
ObjectSetInteger(0, name, OBJPROP_CORNER, CORNER_LEFT_UPPER);
ObjectSetInteger(0, name, OBJPROP_XDISTANCE, orgX + offX);
ObjectSetInteger(0, name, OBJPROP_YDISTANCE, orgY + offY);
ObjectSetInteger(0, name, OBJPROP_XSIZE, width);
ObjectSetInteger(0, name, OBJPROP_YSIZE, height);

ObjectSetString( 0, name, OBJPROP_FONT, “Arial”);
ObjectSetInteger(0, name, OBJPROP_FONTSIZE, font_size);
ObjectSetString( 0, name, OBJPROP_TEXT, text);
ObjectSetInteger(0, name, OBJPROP_COLOR, clr); // Text color
ObjectSetString( 0, name, OBJPROP_TOOLTIP, tip);

ObjectSetInteger(0, name, OBJPROP_BGCOLOR, C’236, 233, 216′);
ObjectSetInteger(0, name, OBJPROP_CORNER, CORNER_LEFT_UPPER);
ObjectSetInteger(0, name, OBJPROP_COLOR, clrBlack);
ObjectSetInteger(0, name, OBJPROP_BORDER_COLOR, clrNONE);
ObjectSetInteger(0, name, OBJPROP_BACK, false);
//— enable (true) or disable (false) the mode of moving the button by mouse
ObjectSetInteger(0, name, OBJPROP_STATE, false);
ObjectSetInteger(0, name, OBJPROP_SELECTABLE, false);
ObjectSetInteger(0, name, OBJPROP_SELECTED, false);
ObjectSetInteger(0, name, OBJPROP_HIDDEN, false);
ObjectSetInteger(0, name, OBJPROP_ZORDER, Priority_Buttons);
} // button_create
//+——————————————————————+
//| Create label. |
//+——————————————————————+
void create_label(string name, int offX, int offY, string text, string tip,
color clr=clrNONE, int font_size=10){
if(clr == clrNONE) clr = ColorText;
ObjectCreate(name, OBJ_LABEL, 0, 0, 0);
ObjectSetInteger(0, name, OBJPROP_XDISTANCE, orgX + offX);
ObjectSetInteger(0, name, OBJPROP_YDISTANCE, orgY + offY);
ObjectSetInteger(0, name, OBJPROP_SELECTABLE, false);
ObjectSetText(name, text, font_size, “Courier New”, clr);
ObjectSetString(0, name, OBJPROP_TOOLTIP, tip);
} // create_label
//+——————————————————————+
//| Create text object. |
//+——————————————————————+
void create_text(string name, double price, string text, color clr,
int font_size=10){
ObjectCreate(name, OBJ_TEXT, 0, Time[2], price);
ObjectSetInteger(0, name, OBJPROP_ANCHOR, ANCHOR_RIGHT_UPPER);
ObjectSetText(name, text, font_size, “Courier New”, clr);
ObjectSetString(0, name, OBJPROP_TOOLTIP, text);
} // create_text
//+——————————————————————+
//| Create Trend line |
//+——————————————————————+
void create_tLine(string name,
datetime time1, double price1,
datetime time2, double price2,
color clr,
ENUM_LINE_STYLE style=STYLE_DOT){
ObjectCreate(name, OBJ_TREND, WINDOW_MAIN, time1, price1, time2, price2);
ObjectSetInteger(0, name, OBJPROP_COLOR, clr);
ObjectSetInteger(0, name, OBJPROP_STYLE, style);
ObjectSetInteger(0, name, OBJPROP_RAY, false);
}
//+——————————————————————+
//| Create Arrow |
//+——————————————————————+
void create_arrow(string name,
datetime time, double price,
int code,
color clr){
ObjectCreate(name, OBJ_ARROW, WINDOW_MAIN, time, price);
ObjectSetInteger(0, name, OBJPROP_COLOR, clr);
ObjectSetInteger(0, name, OBJPROP_ARROWCODE, code);
}
//+——————————————————————+
//| Create Order result |
//+——————————————————————+
void create_trades(bool doAlert){ // Order is selected.
int ot = OrderType();
color clr = ot == OP_BUY ? Blue : Red;
string op = as_string( (Trade_Operation)ot);

datetime from = OrderOpenTime(), to = OrderCloseTime();
double oop = OrderOpenPrice(), ocp = OrderClosePrice();
string open = price_as_string(oop);
string close = price_as_string(ocp);

string lots = lots_as_string(OrderLots() );
int ticket = OrderTicket();

string tLine = StringFormat(“#%i %s -> %s”, ticket, open, close);
if(doAlert && ObjectFind(tLine) < 0)
Alert(StringFormat(“closed %i on %s”,ticket,_Symbol)); // expert.wav;
/*void*/ create_tLine(tLine,
from, oop, to, ocp, clr);
/*void*/ create_arrow(StringFormat(“#%i %s %s %s at %s”,
ticket, op, lots, _Symbol, open),
from, oop, 1, clr);
/*void*/ create_arrow(StringFormat(“#%i %s %s %s at %s close at %s”,
ticket, op, lots, _Symbol, open, close),
to, ocp, 3, Goldenrod);
}
void delete_trades(void){ ObjectsDeleteAll(0, “#”); }
//+——————————————————————+
